Structural Steel Detailing
"Fabrication-ready drawings with minimal back-and-forth."
- —Shop drawings (beams, columns, braces)
- —Anchor bolt plans
- —Erection drawings
- —Section & detail views
- —Clean, easy-to-fabricate output — AISC compliant
Services
End-to-end steel detailing deliverables.
From core structural detailing through connection design, BIM coordination, and shop-floor deliverables — scoped to what you need, as fabricator, as erector.
Core services
Where every project starts.
Connection Design & Detailing
"End-to-end detailing + connection design — fewer coordination issues."
- —Shear, moment and bracing connections
- —Calculations (stamped via partner engineer when required)
- —Connection sketches integrated into drawings
3D Modeling
"Model-driven detailing for accuracy and fabrication automation."
- —Accurate 3D models
- —Model-based drawings
- —CNC / DSTV export from source model
BIM Coordination & Clash Detection
"Avoid costly site fixes by resolving clashes early."
- —Clash detection (Steel vs MEP)
- —Coordination meeting support
- —Model revisions and federation
Estimation Support
"Helping you bid faster and more accurately."
- —Material takeoffs
- —Preliminary tonnage
- —Budget pricing support
Miscellaneous Steel Detailing
"Fabrication-ready drawings for architectural and support steel components."
- —Shop drawings for stairs, railings, ladders, and platforms
- —Canopies, catwalks, grating, and miscellaneous assemblies
- —Connection and attachment details
- —Section, elevation & detail views
- —Clean, easy-to-fabricate output — AISC compliant
Priorities
What fabricators actually care about.
- Turnaround time — deadlines matter more than anything
- Communication — quick replies over perfect polish
- Fewer RFIs — this is huge
- Familiarity with AISC / OSHA practices
- Ability to scale when your shop is overloaded
Supporting & value-added
Deliverables that plug directly into your shop.
Fabrication Deliverables (CNC / DSTV / KISS)
"Ready-to-fabricate digital output — plug into your shop floor."
- —CNC files (DSTV, DXF) or as required
- —Plate nesting support
- —Bolt lists & material lists
As-Built Drawings & Revisions
"Accurate documentation for project closeout and future reference."
- —Incorporating site changes
- —Final as-built drawing sets
- —Structured revision tracking
